RW-C3405 HP
Product Features:
- Durable and light body using aluminum alloy.
- Presented in wide frequency bands.
- Rust-resistant base using Geomint coating process.
- Ideal for use in long distances up to +80 km.
- Resistant to force rotating the antenna when the wind blows.
- Easy antenna tuning and installation using new phase bases.
- Compatible with all market radios such as: Mimosa, MikroTik, LigoWave and Ubiquiti.
Description
RayaWave brand RW-C3405 HP antenna with a diameter of +102cm is used for data transmission in long distances up to +80km.
The depth optimization of this antenna has been standardized so that it can have a very good signal in environments with high frequency pollution. This antenna is of the HP or High-Performance type.
The type of base or mount kit of this antenna is an easy mount kit, and the Geomint coating process is used in the construction of the base to resist erosion and rust as much as possible.
This product is fully compatible with all radios in the market, especially MikroTik, Mimosa and LigoWave radios.
This antenna is offered in two separate frequency bands of 5 and 6 GHz with the same price. Also, this antenna can be customized for use with Mimosa X series products at the same price.
Additional information
| Product Model | RW-C3405 HP |
|---|---|
| Antenna Type | Parabolic Solid Dish Antenna |
| Frequency Range | 4.7 – 6.4 Ghz |
| Impedance | 50 Ω |
| Polarization | Vertical and Horizental |
| Antenna Gain | 34 dBi |
| Waight | net: 13500 gr |
| S.W.R in Bandwidth | <1.4:1(TyP) |
| Single Unit Dimension | 1020 × 1020 × 472mm |
| Oprating Temprature | -40C° to +80C° |
| Wind Resistance | 200/150 km/h |
| H/E plan beamwidth | 3.1 degree |
| Connector Type | 2x Ntype-Female RP Connectors |
| Mechanical Pan/Tilt | ±15° |
| Max/Min Gain | in 6400Mhz(34.7dBi) & in 4700Mhz(32dBi) |
| Front to Back Ratio | ≥56dB |
| ETSI Specification | EN 302 326 DN2-DN5 |
| Mounting Kit Style | Easy Mount Kit |
| Materials | Aluminium alloy and UV Resistant polimer |
| F/D Ratio | 0.25 |
